USA flag. Handcrafted in USA
Defoamer Cup

PRICE$23.00

5

Defoamer Cup

SKU: SL-DCUP
Defoamer Cup
Defoamer Cup Defoamer Cup Defoamer Cup
PRICE

$23.00

AVG, SHIPPING TIME

Timing is based on our current production timeline.

Unparalleled Support

Distributed by Smoky Lake

Your Partner in Maple

Tested and Approved

Premium Maple Equipment

Description

1. Installation

Install the cup simply by wrapping the flexible metal strap over the top edge of your pan. If you have a continuous flow pan, place the defoamer cup near the pan’s inlet port (the location in which sap enters the pan). Position the cup high enough to not come in contact with sap while it is boiling normally. Note that the attachment strap is flexible and customizable to fit any evaporator pan.

2. Choose the Right Defoamer

Before you start boiling, you will need to place a few drops of defoamer in the cup. There are commercial defoamers available on the market. However, all you really need is a few drops of organic canola oil or vegetable oil from your local grocery store. It is also possible to use a sliver of butter as defoamer, but keep in mind some folks are extremely sensitive/allergic of dairy products. If you are running an organic farm, choose an organic defoamer that does not contain allergens.

If your syrup tastes oily, you are using way too much defoamer. Remember that a little tiny bit goes a long way.

3. Prevent Overflow of Foaming Sap

While boiling, sap has a tendency to foam up every once in a while without warning. However, as soon as the rising foam comes in contact with the defoamer in your cup, the foam will dissipate.

You will then need to “reset” your cup with a couple more drops of defoamer to safeguard against the next occurrence of foam.

4. Be Proactive

In addition to using a defoamer cup, you may choose to help prevent foam from ever developing in the first place. Set an egg timer to remind you to add 1 – 2 drops of defoamer directly to your boiling sap about every 10 minutes. If you have a continuous flow pan, remember that defoamer needs to be added by the sap inlet, NOT by the draw-off. By using this approach, you will help prevent foam flare ups, and at the same time you will still have the defoamer cup working as a backup.

We have heard many tales of people who have forgotten to set their timer to add defoamer and were then caught off guard by foam. In those cases a Defoamer Cup would have been a helpful safeguard.

5. Protect Your Pans

If unexpected foam causes sap to overflow your evaporator pan, the sap depth may get too low for safe operation. In that case, the intense heat from the firebox may scorch and warp your pans. There is no way to “fix” pans to make them look new again after they are scorched/warped. Hence, the Defoamer Cup is an effective and low-cost way to protect your evaporator pans/investment.

Specs

Attachment Strap

  • 10-1/4″ length
  • Customizable (one size fits all)
  • Stainless steel

Cup

  • 2-1/4″ top diameter
  • 1-1/2″ bottom diameter
  • 1-5/8″ depth
  • Stainless steel

Tutorials and Tips

5

Defoamer Cup

SKU: SL-DCUP
PRICE

$23.00

AVG, SHIPPING TIME

Timing is based on our current production timeline.

The Defoamer Cup prevents sap from overflowing your evaporator pan during an unexpected foam-up. (Instructions below)

  • 100% food-grade Stainless steel
  • Customizable to fit any evaporator pan
  • Compatible with the defoamer of your choice (see more information below)
  • Lifetime limited warranty on spot welds
  • Approved for use in the production of organic maple syrup (see more information below)
Average Shipping time
car
Free Shipping for Continental US

Description

1. Installation

Install the cup simply by wrapping the flexible metal strap over the top edge of your pan. If you have a continuous flow pan, place the defoamer cup near the pan’s inlet port (the location in which sap enters the pan). Position the cup high enough to not come in contact with sap while it is boiling normally. Note that the attachment strap is flexible and customizable to fit any evaporator pan.

2. Choose the Right Defoamer

Before you start boiling, you will need to place a few drops of defoamer in the cup. There are commercial defoamers available on the market. However, all you really need is a few drops of organic canola oil or vegetable oil from your local grocery store. It is also possible to use a sliver of butter as defoamer, but keep in mind some folks are extremely sensitive/allergic of dairy products. If you are running an organic farm, choose an organic defoamer that does not contain allergens.

If your syrup tastes oily, you are using way too much defoamer. Remember that a little tiny bit goes a long way.

3. Prevent Overflow of Foaming Sap

While boiling, sap has a tendency to foam up every once in a while without warning. However, as soon as the rising foam comes in contact with the defoamer in your cup, the foam will dissipate.

You will then need to “reset” your cup with a couple more drops of defoamer to safeguard against the next occurrence of foam.

4. Be Proactive

In addition to using a defoamer cup, you may choose to help prevent foam from ever developing in the first place. Set an egg timer to remind you to add 1 – 2 drops of defoamer directly to your boiling sap about every 10 minutes. If you have a continuous flow pan, remember that defoamer needs to be added by the sap inlet, NOT by the draw-off. By using this approach, you will help prevent foam flare ups, and at the same time you will still have the defoamer cup working as a backup.

We have heard many tales of people who have forgotten to set their timer to add defoamer and were then caught off guard by foam. In those cases a Defoamer Cup would have been a helpful safeguard.

5. Protect Your Pans

If unexpected foam causes sap to overflow your evaporator pan, the sap depth may get too low for safe operation. In that case, the intense heat from the firebox may scorch and warp your pans. There is no way to “fix” pans to make them look new again after they are scorched/warped. Hence, the Defoamer Cup is an effective and low-cost way to protect your evaporator pans/investment.

Specs

Attachment Strap

  • 10-1/4″ length
  • Customizable (one size fits all)
  • Stainless steel

Cup

  • 2-1/4″ top diameter
  • 1-1/2″ bottom diameter
  • 1-5/8″ depth
  • Stainless steel

Tutorials and Tips
