SapMaster 5/16" Clear Spout – Compatible with 5/16" Tubing (100-Pack)

5

SapMaster 5/16" Clear Spout – Compatible with 5/16" Tubing (100-Pack)

SKU: SM-PROD516-100
Inlet Area Highlight
Spout Detail Side Left Front Back 45 Right Front 45 Right Back
PRICE

$45.00
AVG. LEAD TIME
This is the estimated/average time required to get this product ready and/or shipped. Please note that timing may be faster when picked up at our Hilbert showroom.

Free Shipping

In Continental USA

Learn More

Distributed by Smoky Lake

Your Partner in Maple

Tested and Approved

Premium Maple Equipment

Description

Designed by a sugarmaker, refined by producer feedback. The SapMaster 5/16″ spout was designed by TJ Wood LLC in Rose Creek, Minnesota. After a first season with more than 300,000 taps in the field, the 2026 design was reworked around what producers reported: a tighter seal in the tree, a shorter pilot for smaller trees, and faster installation. SapMaster reports roughly 20% yield improvements in its 2025 testing across a wide range of locations and tree types in Canada.

What Makes It Different

  • Bottom- and front-loading tip. Sap enters through the front of the spout and through an opening on the underside, giving over 30% more inlet area. A stabilizing pilot holds the tip in position so both inlets stay open.
  • Clear polycarbonate body. High-strength, food-grade polycarbonate. You can see at a glance whether a spout is running, plugged, or frozen.
  • Steeper seal taper and bigger starting diameter. Seats firmly in a 5/16″ tap hole and holds vacuum.
  • Shorter pilot. A better fit for younger trees and older sugarbushes. Designed for tap holes under 1-1/2″ deep.
  • Short barb with a smaller starting diameter. Pushes onto 5/16″ tubing easily and is built for one-handed tool installation.
  • No parting line on the barb. A seamless barb helps prevent micro-leaks at the tubing connection.

Installation Tips

  • Drill a 5/16″ tap hole less than 1-1/2″ deep.
  • Install the spout as close to horizontal as possible. Spouts tipped downward are more likely to freeze or push out.
  • Seat the spout with light taps until the sound changes to a flatter thud. Do not twist or rotate the spout once it is in the hole, because twisting can crack it.

Can be used with or without Tubing (drop lines).

FEATURES

  • Tap Hole Compatibility = 5/16″
  • Drill Bit Compatibility = SKU DSD-35M01313
  • Tubing Compatibility = 5/16″
  • Clear, high-strength food-grade polycarbonate
  • Designed to last more than one season
  • Barbed design provides a strong, leak-free grip on tubing
  • Boxed in 100-packs
  • Designed in Minnesota by SapMaster
  • Free shipping in continental USA!

Tutorials and Tips
5

SapMaster 5/16" Clear Spout – Compatible with 5/16" Tubing (100-Pack)

SKU: SM-PROD516-100
PRICE

$45.00
AVG. LEAD TIME
This is the estimated/average time required to get this product ready and/or shipped. Please note that timing may be faster when picked up at our Hilbert showroom.
  • Over 30% more inlet area — the front- and bottom-loading inlet slot is designed to draw more sap than conventional spouts
  • UV Stabilized Clear polycarbonate — see at a glance if a spout is running, plugged, or frozen. Can be used multiple seasons if properly maintained.
  • Steeper seal taper — seats firmly in a 5/16″ tap hole and holds vacuum
  • Short, seamless barb — one-handed tool install and a leak-free grip on tubing
  • Tubing Compatibility —  5/16″
  • Boxed 100-pack — free shipping in the continental USA
1 unit
$45.00
2+ units
$41.00 (8.89% off)
DSD Drill Bit for 5/16" Spouts

5/16" Drill Bit with Plastic Case

  • Compatible with 5/16" taps (Bit diameter = 0.313")
  • Pulls sawdust out of the tap hole much more effectively than a standard drill bit.
  • Very sharp, precise, clean cut.
  • Will NOT leave residue/marking on your tree.
  • Brand = DSD International
  • Made in USA



Average Lead Time
car
Free Shipping for Continental US

Description

Designed by a sugarmaker, refined by producer feedback. The SapMaster 5/16″ spout was designed by TJ Wood LLC in Rose Creek, Minnesota. After a first season with more than 300,000 taps in the field, the 2026 design was reworked around what producers reported: a tighter seal in the tree, a shorter pilot for smaller trees, and faster installation. SapMaster reports roughly 20% yield improvements in its 2025 testing across a wide range of locations and tree types in Canada.

What Makes It Different

  • Bottom- and front-loading tip. Sap enters through the front of the spout and through an opening on the underside, giving over 30% more inlet area. A stabilizing pilot holds the tip in position so both inlets stay open.
  • Clear polycarbonate body. High-strength, food-grade polycarbonate. You can see at a glance whether a spout is running, plugged, or frozen.
  • Steeper seal taper and bigger starting diameter. Seats firmly in a 5/16″ tap hole and holds vacuum.
  • Shorter pilot. A better fit for younger trees and older sugarbushes. Designed for tap holes under 1-1/2″ deep.
  • Short barb with a smaller starting diameter. Pushes onto 5/16″ tubing easily and is built for one-handed tool installation.
  • No parting line on the barb. A seamless barb helps prevent micro-leaks at the tubing connection.

Installation Tips

  • Drill a 5/16″ tap hole less than 1-1/2″ deep.
  • Install the spout as close to horizontal as possible. Spouts tipped downward are more likely to freeze or push out.
  • Seat the spout with light taps until the sound changes to a flatter thud. Do not twist or rotate the spout once it is in the hole, because twisting can crack it.

Can be used with or without Tubing (drop lines).

FEATURES

  • Tap Hole Compatibility = 5/16″
  • Drill Bit Compatibility = SKU DSD-35M01313
  • Tubing Compatibility = 5/16″
  • Clear, high-strength food-grade polycarbonate
  • Designed to last more than one season
  • Barbed design provides a strong, leak-free grip on tubing
  • Boxed in 100-packs
  • Designed in Minnesota by SapMaster
  • Free shipping in continental USA!
