General Guidelines for Determining Smoke Stack Diameter Size:

• 8" Stack Pipe – Compatible with 2' x 3' and 2' x 33" Corsair evaporators
• 10" Stack Pipe – Compatible with all Smoky Lake 2'-wide evaporators, 4 feet pan length or longer
• 12" Stack Pipe – Compatible with all Smoky Lake 30"-wide evaporators
• 14" Stack Pipe – Compatible with Smoky Lake Silverplate 3'-wide evaporators

Calculating Total Height:

Each time you join two sections together, keep in mind that you will loose 2" of total height because of the way the sections inter-lock together. For example, after joining two 2-foot sections, the total height ends up being 3'10" (4 feet - 2 inches).

Removing the Protective Vinyl From the Stack Pipe:

If your stainless stack pipe is shipped with a protective vinyl and/or a caution sticker on it, you MUST remove them BEFORE use. Failing to do so will result in the vinyl/sticker charring to the stainless steel, resulting in a loss of the metal’s inherent beauty.It is easiest to remove the protective vinyl in a warm room. It will not peel off as easily in very cold temperatures.

Materials:

Stainless steel will naturally discolor after it has been subjected to the intense heat of your evaporator. Hence, it is not possible for any stack pipe on a working evaporator to identically match the mirror finish of your Smoky Lake evaporator pans.
